LLY Inner capsule type high efficiency fiber filter
The LLY high-efficiency fiber filter is the first generation of fiber bundle filtration equipment and the first application of long fiber filtration technology. It is composed of shell, filter element, pressure chamber, pipe system, pressure chamber filling and drainage system and other parts. Water passes through the filter from bottom to top when the equipment is in operation. The cleaning method is combined with air and water, and the cleaning effect is good. The filter has the advantages of deep filtration, fast filtration speed, large pollution capacity and good effluent quality.
The pressure grade of all interface flanges of the equipment is pn1.0mpa;
The device is supplied to an interface flange, and the valve is self-reliant.
The scope of supply includes inlet and outlet pressure gauges, inlet and outlet sampling valves.
设备规格型号 model number |
LLY800 |
LLY 1000 |
LLY 1500 |
LLY 2000 |
LLY 2500 |
LLY 3000 |
设备直径(:mm) Equipment diameter |
800 |
1000 |
1500 |
2000 |
2500 |
3000 |
最大流量(m3/h) maximum flow |
15 |
20 |
49 |
91 |
149 |
210 |
滤水面积(m2) the filter area |
0.5 |
0.78 |
1.77 |
3.14 |
4.9 |
7.06 |
过滤速度(m/h) filtration velocity |
20~30 |
|||||
滤层高度(m) filter layer height |
/ |
|||||
操作压力(Mpa) operating pressure |
0.6 |
|||||
截污容量(kg/m3) sewage removal capacity |
10~15 |
|||||
过滤前水质 pre-filtration water quality |
悬浮物 suspended solids(mg/L) |
20 |
||||
浊度 turbidity(NTU) |
20 |
|||||
过滤后水质 filtered water quality |
悬浮物 suspended solids(mg/L) |
≤2 |
||||
浊度 turbidity(NTU) |
≤2 |
|||||
设备参考重量(≈t) reference weight of equipment |
1.6 |
3.0 |
4.2 |
5.8 |
7.3 |
9.5 |
注:表中设备规格仅供参考,具体应以双方签字的设计图纸为准。 Note: the equipment specifications in the table are for reference only, and shall be subject to the design drawing signed by both parties. 详细资料,请联系本公司索取。 Please contact us for further information. |
